1/2” Bore UCP201-8 Pillow Block Bearing

1/2'' Bore UCP201-8 Pillow Block Bearing

GJP Premium quality 1/2″ pillow block bearing with solid base housing. Which has grease zerk on 45 degree angle, and the insert bearing has a wide inner ring with two set screws for locking on the shaft, bearing insert and housing are normally assemblied with J7 tight fitting.

Share on facebook
Share on twitter
Share on linkedin

Product Details

Description-1/2”Bore UCP201-8 Pillow Block Bearing

GJP Bar Code Number: 6935329801981

GJP Premium quality 1/2″ pillow block bearing with solid base housing. Which has grease zerk on 45 degree angle, and the insert bearing has a wide inner ring with two set screws for locking on the shaft, bearing insert and housing are normally assemblied with J7 tight fitting.

Pillow block bearing is a bearing unit that combines rolling bearings and bearing housings. Most of the outer spherical bearings are made of spherical outer diameter and installed together with imported bearing seats with spherical inner holes. They have various structural forms and good versatility and interchangeability.

At the same time, this type of bearing also has a certain self-alignment in design, easy to install, and has a double-structured sealing device, which can work in harsh environments.

Considering that the maintenance of the bearing with seat is not the same as that of other bearings, in fact, it is not the case. The maintenance of the bearing is basically the same.

How to maintain the pillow block bearing

1. Cleaning of pillow block bearing

When removing the bearing for inspection, first take pictures and other methods to make a record of the appearance. Also, acknowledge the amount of remaining lubricant and sample the lubricant before cleaning the bearing.

2. Inspection of pillow block bearing

In order to distinguish whether the removed bearing can be used again, it is necessary to focus on checking its standard accuracy, rotation accuracy, internal clearance, and cooperation surfaces, raceway surfaces, cages and sealing rings. Regarding the inspection effect, it can be distinguished by those who use inertia bearings or those who know bearings. The other criteria for judgment vary according to the function and importance of the machine, as well as the inspection cycle. If the following damage occurs, the bearing shall not be re-used and must be replaced.

GJP is a professional pillow block bearing manufacturers, we have many years of export experience and are one of the experts in this industry. If you are interested in our products, please contact us as soon as possible.



Interchange

GJP: UCP201-8

AMI: UCP201-8

IPTCI: UCP201-8

Fafnir: RASC-1/2”

Fafnir: YAS-1/2”

NSK: UCP201-8

NTN: UCP201-008D1

Peer: FHSP201-8G

RHP: NP-1/2”

Sealmaster: NP-8

SKF: SY 1/2” TF

1/2” Bore UCP201-8 Pillow Block Bearing

Basic Dimensions

Bore Size

Center Shaft to Base Size

Housing Length

Center Bolt to Bolt Size

Housing Width

Housing Bolt Length

Housing Bolt Width

Housing Height

Bolt Size

1/2″

30.2MM

127MM

95MM

38MM

19MM

13MM

62MM

3/8″



Technical Data for GJP UCP201-8

Housing No.: P203

Bearing Insert No.: UC201-8

Material For Bearing Insert: 100% Chrome Steel Gcr15(AISI 52100)

Grade For Steel Ball: G10 Grade Chrome Steel Ball.

Materia of Bearing Cage: #10 Steel

Stopping Pin Material on OD of OR: Chrome Steel Gcr15

Sealing Type: F Seal, L3 Seal And Normal NBR Seal are available for customers’selection.

Set Screw Material: 35CrMo

Grease: 20% to 50% Mobil Grease

Set Screw Surrounding Hardness: HRC49 to HRC 50

Bearing Race and Steel Ball Hardness: HRC59 to HRC62

Bearing Housing Material: HT200 Grey Cast Iron

Housing Color: Green, Blue, Grey, Black Color available.

Whole Unit Assembly Type: J7 Tight Fitting

Housing Weight: 0.33KGS

Quality Control: Under ISO:9001:2008 Certificate

Package: 1*1 Single GJP poly bag+1*1 Single GJP color box+1*1 GJP outer carton

MOQ: 1Set



1/2” Bore UCP201-8 Pillow Block Bearing

1/2” Bore UCP201-8 Pillow Block Bearing

1/2” Bore UCP201-8 Pillow Block Bearing



GJP Advantage:

GJP has advanced computer image processing system, a friendly user interface, which customer could easily install GJP’s production products into their machinery, and GJP offer also the CAD’s designed drawing for every of our products.

GJP could produce the belowing UCPX type pillow block bearing unit also:

GJP   Unit NO. Shaft   Dia d Dimensions(mm) Bolt   Used Bearing No. Housing No. Housing Wt (kg)
(in) (mm) h a e b s2 s1 g w Bi n (in) (mm)
UCPX05-16 1 25 44.4 159 119 51 25 17 18 85 38.1 15.9   1/2 M14 UCX05-16 PX05 1.02
UCPX05 1 25 44.4 159 119 51 25 17 18 85 38.1 15.9   1/2 M14 UCX05 PX05 1.02
UCPX06-19 1  3/16 30 47.6 175 127 57 25 17 20 94 42.9 17.5   1/2 M14 UCX06-19 PX06 1.33
UCPX06-20 1  1/4 30 47.6 175 127 57 25 17 20 94 42.9 17.5   1/2 M14 UCX06-20 PX06 1.33
UCPX06 30 47.6 175 127 57 25 17 20 94 42.9 17.5   1/2 M14 UCX06 PX06 1.33
UCPX07-22 1  3/8 35 54 203 144 57 30 17 22 105 49.2 19   1/2 M14 UCX07-22 PX07 1.71
UCPX07-23 1  7/16 35 54 203 144 57 30 17 22 105 49.2 19   1/2 M14 UCX07-23 PX07 1.71
UCPX07 35 54 203 144 57 30 17 22 105 49.2 19   1/2 M14 UCX07 PX07 1.71
UCPX08-24 1  1/2 40 58.7 222 156 67 32 20 26 113 49.2 19   5/8 M16 UCX08-24 PX08 2.09
UCPX08 40 58.7 222 156 67 32 20 26 113 49.2 19   5/8 M16 UCX08 PX08 2.09
UCPX09-26 1  5/8 45 58.7 222 156 67 33 20 26 116 51.6 19   5/8 M16 UCX09-26 PX09 2.3
UCPX09-27 1   11/16 45 58.7 222 156 67 33 20 26 116 51.6 19   5/8 M16 UCX09-27 PX09 2.3
UCPX09-28 1  3/4 45 58.7 222 156 67 33 20 26 116 51.6 19   5/8 M16 UCX09-28 PX09 2.3
UCPX09 45 58.7 222 156 67 33 20 26 116 51.6 19   5/8 M16 UCX09 PX09 2.3
UCPX10-31 1   15/16 50 63.5 241 171 73 36 20 27 126 55.6 22.2   5/8 M16 UCX10-31 PX10 2.85
UCPX10-32 2 50 63.5 241 171 73 36 20 27 126 55.6 22.2   5/8 M16 UCX10-32 PX10 2.85
UCPX10 50 63.5 241 171 73 36 20 27 126 55.6 22.2   5/8 M16 UCX10 PX10 2.85
UCPX11-35 2  3/8 55 69.8 260 184 79 36 25 30 139 65.1 25.4   3/4 M20 UCX11-35 PX11 4.04
UCPX11 55 69.8 260 184 79 36 25 30 139 65.1 25.4   3/4 M20 UCX11 PX11 4.04
UCPX12-38 2  3/8 60 76.2 286 203 83 41 25 32 151 65.1 25.4   3/4 M20 UCX12-38 PX12 4.85
UCPX12-39 2  7/16 60 76.2 286 203 83 41 25 32 151 65.1 25.4   3/4 M20 UCX12-39 PX12 4.85
UCPX12 60 76.2 286 203 83
