20mm Pillow Type Housing UCP204 for Laser Cutting Machine

20mm Pillow Type Housing UCP204 for Laser Cutting Machine

GJP 20mm bore Pillow Block Bearing UCP204 with solid base housing and radial insert ball bearing with grub set screw to lock to the shaft. Which is smaller size and has grease zerk on 45 degree angle, and the insert bearing has a wide inner ring with spherical outer diameter, and there are four star seal and with ball point set screw, bearing insert and housing are normally assemblied with J7 tight fitting.

Share on facebook
Share on twitter
Share on linkedin

Product Details

Description-20mm Metric Bore UCP204 Bearing For Laser Cutting Machine

GJP Bar Code Number: 6935329800595

GJP 20mm bore Pillow Block Bearing For Laser Cutting Machine UCP204 with solid base housing and radial insert ball bearing with grub set screw to lock to the shaft. Which is smaller size and has grease zerk on 45 degree angle, and the insert bearing has a wide inner ring with spherical outer diameter, and there are four star seal and with ball point set screw, bearing insert and housing are normally assemblied with J7 tight fitting.



How to choose the right bearing for laser cutting machine?

  1. The anti-rust treatment on some bearings is not good, and there will be thick oil stains on the bearings. Try not to choose such bearings;
  2. Try to rotate the bearing for laser cutting machine to see if there will be some noise, the quality of the bearing with noise is usually unqualified;
  3. The brand name of the cutting machine can also judge the quality of the entire bearing. The quality of the bearing with unclear words is usually not guaranteed.

The above methods can be used to select the appropriate bearing for laser cutting machine, which can judge the quality of the bearing for laser cutting machine and ensure the normal operation of the laser cutting machine.



Interchange

GJP: UCP204

AMI: UCP204

IPTCI: UCP204

NSK: UCP204

Peer: FHSP204G

Fafnir: RASC-20

Fafnir: YAS-20

RHP: NP-20

SKF: SY 20 TF

Sealmaster:



20mm Pillow Type Housing UCP204 for Laser Cutting Machine

Basic Dimensions

Bore Size

Center Shaft to Base Size

Housing Length

Center Bolt to Bolt Size

Housing Width

Housing Bolt Length

Housing Bolt Width

Housing Height

Bolt Size

20MM

33.3MM

127MM

95MM

38MM

19MM

13MM

65MM

M10



Technical Data for GJP UCP204

Housing No.: P204

Bearing Insert No.: UC204

Material For Bearing Insert: 100% Chrome Steel Gcr15(AISI 52100)

Grade For Steel Ball: G10 Grade Chrome Steel Ball.

Materia of Bearing Cage: #10 Steel

Stopping Pin Material on OD of OR: Chrome Steel Gcr15

Sealing Type: F Seal, L3 Seal And Normal NBR Seal are available for customers’selection.

Set Screw Material: 35CrMo

Grease: 20% to 50% Mobil Grease

Set Screw Surrounding Hardness: HRC49 to HRC 50

Bearing Race and Steel Ball Hardness: HRC59 to HRC62

Bearing Housing Material: HT200 Grey Cast Iron

Housing Color: Green, Blue, Grey, Black Color available.

Whole Unit Assembly Type: J7 Tight Fitting

Housing Weight: 0.46KGS

Quality Control: Under ISO: 9001: 2008 Certificate

Package: 1*1 Single GJP poly bag+1*1 Single GJP color box+1*1 GJP outer carton



20mm Pillow Type Housing UCP204 for Laser Cutting Machine

20mm Pillow Type Housing UCP204 for Laser Cutting Machine

20mm Pillow Type Housing UCP204 for Laser Cutting Machine

20mm Pillow Type Housing UCP204 for Laser Cutting Machine



GJP advantage:

GJP have big and enough molds room for each size and different brands for our customers, if customers need to produce according to assigned brand, we could just

Easily pick up the according item and brand on the sand-casting mold and easily form the exact products customers need at their purchasing orders, GJP have enough molding for all heavy duty items products.



GJP could produce the belowing HCAK type Bearing Unit also:

GJP   Unit.No shaft   Dia. Dimensions(mm) Bolt Size Bearing.No Housing No. Mass(kg)
d H L J A N N1 H1 H0 S B1
(in.) (mm)
 HCAK202 15 31.8 128 98 38 11 14 14 63 17 43.5 M10 HC202 AK204 0.73
 HCAK202-10   5/8 31.8 128 98 38 11 14 14 63 17 43.5 M10 HC202-10 AK204 0.73
 HCAK203 17 31.8 128 98 38 11 14 14 63 17 43.5 M10 HC203 AK204 0.73
 HCAK203-11  11/16 31.8 128 98 38 11 14 14 63 17 43.5 M10 HC203-11 AK204 0.73
 HCAK204-12   3/4 31.8 128 98 38 11 14 14 63 17 43.5 M10 HC204-12 AK204 0.73
 HCAK204 20 31.8 128 98 38 11 14 14 63 17 43.5 M10 HC204 AK204 0.73
 HCAK205-14   7/8 33.3 140 105 40 11 14 15 66.5 17.4 44.3 M10 HC205-14 AK205 0.8
 HCAK205-15  15/16 33.3 140 105 40 11 14 15 66.5 17.4 44.3 M10 HC205-15 AK205 0.8
 HCAK205 25 33.3 140 105 40 11 14 15 66.5 17.4 44.3 M10 HC205 AK205 0.8
 HCAK205-16 1 33.3 140 105 40 11 14 15 66.5 17.4 44.3 M10 HC205-16 AK205 0.8
 HCAK206-18 1  1/8 39.7 160 121 44 14 19 17 79 18.2 48.3 M12 HC206-18 AK206 1.33
 HCAK206 30 39.7 160 121 44 14 19 17 79 18.2 48.3 M12 HC206 AK206 1.33
 HCAK206-19 1  3/16 39.7 160 121 44 14 19 17 79 18.2 48.3 M12 HC206-19 AK206 1.33
 HCAK206-20 1  1/4 39.7 160 121 44 14 19 17 79 18.2 48.3 M12 HC206-20 AK206 1.33
 HCAK207-20 1  1/4 46 167 127 48 14 19 18 91 18.8 51.1 M12 HC207-20 AK207 1.65
 HCAK207-21 1  5/16 46 167 127 48 14 19 18 91 18.8 51.1 M12 HC207-21 AK207 1.65
 HCAK207-22 1  3/8 46 167 127 48 14 19 18 91 18.8 51.1 M12 HC207-22 AK207 1.65
 HCAK207 35 46 167 127 48 14 19 18 91 18.8 51.1 M12 HC207 AK207 1.65
 HCAK207-23 1  7/16 46 167 127 48 14 19 18 91 18.8 51.1 M12 HC207-23 AK207 1.65
 HCAK208-24 1  1/2 49.2 181 140 52 14 19 19 98 21.4 56.3 M12 HC208-24 AK208 2
 HCAK208-25 1  9/16 49.2 181 140 52 14 19 19 98 21.4 56.3 M12 HC208-25 AK208 2
 HCAK208 40 49.2 181 140 52 14 19 19 98 21.4 56.3 M12 HC208 AK208 2
 HCAK209-26 1  5/8 52.4 189 146 54 14 19 20 105 21.4 56.3 M12 HC209-26 AK209 2.42
 HCAK209-27 1  5/8 52.4 189 146 54 14 19 20 105 21.4 56.3 M12 HC209-27 AK209 2.42
 HCAK209-28 1  3/4 52.4 189 146 54 14 19 20 105 21.4 56.3 M12 HC209-28 AK209 2.42
 HCAK209 45 52.4 189 146 54 14 19 20 105 21.4 56.3 M12 HC209 AK209 2.42
 HCAK210-30 1  7/8 55.6 203 159 57 14 19 21 111.5 24.6 62.7 M12 HC210-30 AK210 2.75
 HCAK210-31 1   15/16 55.6 203 159 57 14 19 21 111.5 24.6 62.7 M12 HC210-31 AK210 2.75
 HCAK210-31 1   15/16 55.6 203 159 57 14 19 21 111.5 24.6 62.7 M12 HC210-31 AK210 2.75
 HCAK210 50 55.6 203 159 57 14 19 21 111.5 24.6 62.7 M12 HC210 AK210 2.75
 HCAK211-32 2 61.9 232 181 60 18 24 23 123 27.7 71.3 M16 HC211-32 AK211 3.56
 HCAK211-34 2  1/8 61.9 232 181 60 18 24 23 123 27.7 71.3 M16 HC211-34 AK211 3.56
 HCAK211 55 61.9 232 181 60 18 24 23 123 27.7 71.3 M16 HC211 AK211 3.56
 HCAK211-35 5 61.9 232 181 60 18 24 23 123 27.7 71.3 M16 HC211-35 AK211 3.56
 HCAK212-36 2  1/4 68.3 241 191 64 18 24 25 136 30.9 77.7 M16 HC212-36 AK212 5.2
 HCAK212-36 60 68.3 241 191 64 18 24 25 136 30.9 77.7 M16 HC212 AK212 5.2
 HCAK212-38 2  3/8 68.3 241 191 64 18 24 25 136 30.9 77.7 M16 HC212-38 AK212 5.2
 HCAK212-39 2  7/16 68.3 241 191 64 18 24 25 136 30.9 77.7 M16 HC212-39 AK212 5.2
 HCAK213-40 2  1/2 68.3 248 194 70 18 29 27 141 34.1 85.7 M16 HC213-40 AK213 6.3
 HCAK213 65 68.3 248 194 70 18 29 27 141 34.1 85.7 M16 HC213 AK213 6.3



FAQ

What products can your company supply? From which Inner diameter to which diameter?

GJP bearing company produce by ourself Mounted Unit Bearings, which include Pillow Block Bearings, 2-Bolt Flanged Bearing, 3-Bolt flanged Bearing, 4-Bolt Flanged Bearings, Take-Up unit Bearings, Hanger Bearings, plummer block, our sizes shaft diameter range from 12MM to 90 MM sizes(from size 201 to size 218) for pillow block Bearings, for some special casting products, if customers could supply us the samples or send us the according drawings, then we have the capacity to develop for you according to your supplied technical information, now we also produce some of other casting products for industry or agricultural application.
