2 5/16” Pillow Block Bearing UCP212-37 for Cotton and Wool Processing Equipment

2 5/16'' Pillow Block Bearing UCP212-37 for Cotton and Wool Processing Equipment

GJP 2 5/16″ Pillow Block Bearing UCP212-37 For Cotton and Wool Processing Equipment, Which has grease fitting and Cap on 45 degree angle, and the insert bearing has a wide inner ring with two set screws for locking on the shaft, bearing insert and housing are normally assemblied with J7 tight fitting, this items are widely used.

SKU 442c10bb8d5c Category
Share on facebook
Share on twitter
Share on linkedin

Product Details

Description-2 5/16”Bore Miniature Pillow Block Bearings Unit UCP212-37

GJP Bar Code Number: 6935329802322

GJP 2 5/16″ Miniature Pillow Block Bearings UCP212-37 For Cotton and Wool Processing Equipment, Which has grease fitting and Cap on 45 degree angle, and the insert bearing has a wide inner ring with two set screws for locking on the shaft, bearing insert and housing are normally assemblied with J7 tight fitting, this items are widely used.

Miniature pillow block bearings can be used for: laser welding machine, cotton and linen wool preliminary processing equipment, thread rolling machine, filter press, vertical reducer, dry cleaning machine, weaving machine, fruit and vegetable processing equipment, heater, loading machinery, multi-stage Pumps, strength testing machines, bellows equipment, crushing equipment, industrial drying ovens, bronzing machines, powder equipment, punching machines, etc.



Interchange

GJP: UCP212-37

AMI: UCP212-37

IPTCI: UCP212-37

NSK: UCP212-37

Peer: FHSP212-37G

Fafnir: RASC-2 5/16”

Fafnir: YAS-2 5/16”

RHP: NP-2 5/16”

SKF: SY 2 5/16”TF



2 5/16'' Pillow Block Bearing UCP212-37 for Cotton and Wool Processing Equipment



Basic Dimensions

Bore Size

Center Shaft to Base Size

Housing Length

Center Bolt to Bolt Size

Housing Width

Housing Bolt Length

Housing Bolt Width

Housing Height

Bolt Size

2 5/16″

69.8MM

241MM

187MM

70MM

25MM

20MM

138MM

5/8



Technical Data for GJP UCP212-37

Housing No.: P212

Bearing Insert No.: UC212-37

Material For Bearing Insert: 100% Chrome Steel Gcr15(AISI 52100)

Grade For Steel Ball: G10 Grade Chrome Steel Ball.

Materia of Bearing Cage: #10 Steel

Stopping Pin Material on OD of OR: Chrome Steel Gcr15

Sealing Type: F Seal, L3 Seal And Normal NBR Seal are available for customers’selection.

Set Screw Material: 35CrMo

Grease: 20% to 50% Mobil Grease

Set Screw Surrounding Hardness: HRC49 to HRC 50

Bearing Race and Steel Ball Hardness: HRC59 to HRC62

Bearing Housing Material: HT200 Grey Cast Iron

Housing Color: Green, Blue, Grey, Black Color available.

Whole Unit Assembly Type: J7 Tight Fitting

Housing Weight: 2.8KGS

Quality Control: Under ISO: 9001: 2008 Certificate

Package: 1*1 Single GJP poly bag+1*1 Single GJP color box+1*1 GJP outer carton



2 5/16'' Pillow Block Bearing UCP212-37 for Cotton and Wool Processing Equipment

2 5/16'' Pillow Block Bearing UCP212-37 for Cotton and Wool Processing Equipment

2 5/16'' Pillow Block Bearing UCP212-37 for Cotton and Wool Processing Equipment

2 5/16'' Pillow Block Bearing UCP212-37 for Cotton and Wool Processing Equipment



GJP advantage:

GJP stick to the principle with mutual benefits for GJP and our buyers, we keeps small profits, quick cash-flowing and products delivery time, Our company’s big productin line, hornor-keeping,contract-promising,product quality-gurantee,won the trust of customers under the

Principle of various categories and low price. Welcome old and new customers from domestic & abroad call or visiting to our company for consultations and negotiations.Consecutive sales increasement of around 10 years.



FAQ

We are from New Delhi in India, and we’re bearing importers here, we used to buy from one company in China for 10000pcs of UCF206 with Heavy Duty housing, four star F- seals, but when our end users assemble the bearing into the punching machine, and the seals comes out, what’s the reason?

For this problem, if you purchasing the F seal bearing unit from your factory, then please tell them that you need to do the testing for greasing from the nipple by using the grease gun, then you could check the pressure after you grease your bearings, if the grease volumn is up to 80 to 90%, please check the F seal situation, whether it comes out or not, and also check the mounting situation between seal and outer diameter of inner ring and inner diameter of outer ring, whether the seal is mounted correctly or not.
