85mm Pillow Block Bearing UCP217 for Coal Mill Machine

Description-85mm Bore Pillow Block Bearing UCP217

GJP Bar Code Number: 6935329802506

GJP 85mm Pillow Block Bearing UCP217 For Coal Mill Machine, Which has grease fitting and Cap on 45 degree angle, and the insert bearing has a wide inner ring with two set screws for locking on the shaft, bearing insert and housing are normally assemblied with J7 tight fitting, this items are widely used.

Interchange

GJP: UCP217

AMI: UCP217

IPTCI: UCP217

NSK: UCP217

Peer: FHSP217G

Fafnir: RASC-85

Fafnir: YAS-85

RHP: NP-85

SKF: SY 85″ TF

Technical Data for GJP UCP217

Housing No.: P217

Bearing Insert No.: UC217

Material For Bearing Insert: 100% Chrome Steel Gcr15(AISI 52100)

Grade For Steel Ball: G10 Grade Chrome Steel Ball.

Materia of Bearing Cage: #10 Steel

Stopping Pin Material on OD of OR: Chrome Steel Gcr15

Sealing Type: F Seal, L3 Seal And Normal NBR Seal are available for customers’selection.

Set Screw Material: 35CrMo

Grease: 20% to 50% Mobil Grease

Set Screw Surrounding Hardness: HRC49 to HRC 50

Bearing Race and Steel Ball Hardness: HRC59 to HRC62

Bearing Housing Material: HT200 Grey Cast Iron

Housing Color: Green, Blue, Grey, Black Color available.

Whole Unit Assembly Type: J7 Tight Fitting

Housing Weight: 6.9KGS

Quality Control: Under ISO: 9001: 2008 Certificate

Package: 1*1 Single GJP poly bag+1*1 Single GJP color box+1*1 GJP outer carton
