80mm Pillow Block Bearing UCP216 for Glass Machine Engineering

Description-80mm Bore Pillow Block Bearing For Glass Machine Engineering UCP216

GJP Bar Code Number: 6935329802483

GJP 80mm Pillow Block Bearing For Glass Machine Engineering UCP216, which has grease fitting and cap on 45 degree angle, and the insert bearing has a wide inner ring with two set screws for locking on the shaft, bearing insert and housing are normally assemblied with J7 tight fitting, this items are widely used.

Glass machinery mainly refers to the industrial machinery and equipment used in the production and processing of glass. GJP has been engaged in the production and export of bearing for glass machine engineering for many years. If you want to know more about our products, please feel free to contact us.

Interchange

GJP: UCP216

AMI: UCP216

IPTCI: UCP216

NSK: UCP216

Peer: FHSP216G

Fafnir: RASC-80

Fafnir: YAS-80

RHP: NP-80

SKF: SY 80″ TF

Technical Data for GJP UCP216

Housing No.: P216

Bearing Insert No.: UC216

Material For Bearing Insert: 100% Chrome Steel Gcr15(AISI 52100)

Grade For Steel Ball: G10 Grade Chrome Steel Ball.

Materia of Bearing Cage: #10 Steel

Stopping Pin Material on OD of OR: Chrome Steel Gcr15

Sealing Type: F Seal, L3 Seal And Normal NBR Seal are available for customers’selection.

Set Screw Material: 35CrMo

Grease: 20% to 50% Mobil Grease

Set Screw Surrounding Hardness: HRC49 to HRC 50

Bearing Race and Steel Ball Hardness: HRC59 to HRC62

Bearing Housing Material: HT200 Grey Cast Iron

Housing Color: Green, Blue, Grey, Black Color available.

Whole Unit Assembly Type: J7 Tight Fitting

Housing Weight: 5.8KGS

Quality Control: Under ISO: 9001: 2008 Certificate

Package: 1*1 Single GJP poly bag+1*1 Single GJP color box+1*1 GJP outer carton

FAQ

Can your products used on the aeroplane?

For the aeroplane bearing, sorry that we don’t supply it, as it’s very important for the bearings request if you wanna to apply on airplance, which requires high speed, high friction, as for this kind of bearings, we don’t produce by ourself, if we buy from outsides, we could not understand fully on the quality, so we don’t wanna to take a risk, I suggest that you could buy this type of bearings from SKF, FAG or Timken or some other Japanese brand, who have more experiences on it, or you could take a try to confirm with some other Chinese bearings like CX, C&U, TMB, TWB, ZWZ, HRB, or LYC or ZYS etc.
