2 9/16” Pillow Block Bearing UCP213-41 for Compressors

2 9/16'' Pillow Block Bearing UCP213-41 for Compressors

GJP 2 9/16″ Pillow Block Bearing UCP213-41 For Compressors, Which has grease fitting and Cap on 45 degree angle, and the insert bearing has a wide inner ring with two set screws for locking on the shaft, bearing insert and housing are normally assemblied with J7 tight fitting, this items are widely used.

SKU 8698a28c7fad Category
Share on facebook
Share on twitter
Share on linkedin

Product Details

Description-2 9/16”Bore Pillow Block Bearing For Compressors UCP213-41

GJP Bar Code Number: 6935329802360

GJP 2 9/16″ Pillow Block Bearing For Compressors UCP213-41, Which has grease fitting and Cap on 45 degree angle, and the insert bearing has a wide inner ring with two set screws for locking on the shaft, bearing insert and housing are normally assemblied with J7 tight fitting, this items are widely used, the tolerance GJP process is +.000/-.002 inch, and the dynamic loading rating belowing is based on a rated life of 90 million revolutions, if the application loads approach or exceed the maximum allowable slip fit radial load, then the shaft fit should be adjusted to line to line or light press fit.

The pillow block bearing for compressors produced by GJP feature high dimensional and clearance consistency, high rotational accuracy, and low noise. It is very suitable for compressor applications with high axial and radial positioning accuracy, and the requirements of clearance exchange, which is convenient for production assembly and maintenance and replacement.



Interchange

GJP: UCP213-41

AMI: UCP213-41

IPTCI: UCP213-41

NSK: UCP213-41

Peer: FHSP213-41G

Fafnir: RASC-2 9/16″

Fafnir: YAS-2 9/16″

RHP: NP-2 9/16″

SKF: SY 2 9/16″ TF

2 9/16'' Pillow Block Bearing UCP213-41 for Compressors

Basic Dimensions

Bore Size

Center Shaft to Base Size

Housing Length

Center Bolt to Bolt Size

Housing Width

Housing Bolt Length

Housing Bolt Width

Housing Height

Bolt Size

2 9/16″

76.2MM

265MM

203MM

70MM

29MM

25MM

151MM

3/4



Technical Data for GJP UCP213-41

Housing No.: P213

Bearing Insert No.: UC213-41

Material For Bearing Insert: 100% Chrome Steel Gcr15(AISI 52100)

Grade For Steel Ball: G10 Grade Chrome Steel Ball.

Materia of Bearing Cage: #10 Steel

Stopping Pin Material on OD of OR: Chrome Steel Gcr15

Sealing Type: F Seal, L3 Seal And Normal NBR Seal are available for customers’selection.

Set Screw Material: 35CrMo

Grease: 20% to 50% Mobil Grease

Set Screw Surrounding Hardness: HRC49 to HRC 50

Bearing Race and Steel Ball Hardness: HRC59 to HRC62

Bearing Housing Material: HT200 Grey Cast Iron

Housing Color: Green, Blue, Grey, Black Color available.

Whole Unit Assembly Type: J7 Tight Fitting

Housing Weight: 3.5KGS

Quality Control: Under ISO: 9001: 2008 Certificate

Package: 1*1 Single GJP poly bag+1*1 Single GJP color box+1*1 GJP outer carton



2 9/16'' Pillow Block Bearing UCP213-41 for Compressors

2 9/16'' Pillow Block Bearing UCP213-41 for Compressors

2 9/16'' Pillow Block Bearing UCP213-41 for Compressors

2 9/16'' Pillow Block Bearing UCP213-41 for Compressors



FAQ

What’s your production capacities? How much could you produce out per month?

Now we have three sets of electric stoves, which could have allow us to maximum produce 700Tons housing every months, but as we have some other spcial casting which is not housing, so now totally every month we could produce out around 500tons bearing housing, for the quantity of bearing housing, we could not give exactly, as it’s different for different sizes, for bigger size, the quanity is small, otherwise, it’s bigger quantity for small sizes, and for the ball bearing inserts, we could produce 0.4Million pieces of quantity monthly for the maximum, if there is bigger order quantity, GJP would be very glad to buy more machinery to satisfy the needs.
