2 1/16” NTN Four Star Seal Pillow Block Bearing UCP211-33

2 1/16'' NTN Four Star Seal Pillow Block Bearing UCP211-33

GJP 2 1/16″ NTN Four Star Seal Pillow Block Bearing UCP211-33, Which has grease fitting and Cap on 45 degree angle, and the insert bearing has a wide inner ring with two set screws for locking on the shaft, bearing insert and housing are normally assemblied with J7 tight fitting, this items are widely used.

SKU 2fc82d934fb1 Category
Share on facebook
Share on twitter
Share on linkedin

Product Details

Description-2 1/16”Bore Four Star Seal Pillow Block Bearing Unit UCP211-33

GJP Bar Code Number: 6935329802278

GJP 2 1/16″ NTN Four Star Seal Pillow Block Bearing UCP211-33, Which has grease fitting and Cap on 45 degree angle, and the insert bearing has a wide inner ring with two set screws for locking on the shaft, bearing insert and housing are normally assemblied with J7 tight fitting, this items are widely used.



Advantages of Four Star Seal Pillow Block Bearing:

  • The sealing is reliable, the sealing state is very stable during long-term operation, and the leakage is small, and the leakage is about 1% of the soft packing seal;
  • Long service life, generally 1 to 2 years or longer in oil and water media, and can generally work for more than half a year in chemical media;
  • The friction power consumption is small, and the friction power is only 10% to 50% of the soft packing seal;
  • The shaft or bushing is basically not worn;
  • The maintenance cycle is long, and the end face can be automatically compensated after wear, and regular maintenance is generally not required;
  • Good vibration resistance, insensitive to the vibration of the rotating shaft and the deflection of the shaft to the sealing chamber;
  • Wide range of applications, four star seal pillow block bearing can be used for sealing at high temperature, low temperature, high pressure, vacuum, different rotation frequencies, as well as various corrosive media and media containing abrasive particles.
  •

    Interchange

    GJP: UCP211-33

    AMI: UCP211-33

    IPTCI: UCP211-33

    NSK: UCP211-33

    Peer: FHSP211-33G

    Fafnir: RASC-2 1/16”

    Fafnir: YAS-2 1/16”

    RHP: NP-2 1/16”

    SKF: SY 2 1/16”TF

    Sealmaster: NP-33



    2 1/16” NTN Four Star Seal Pillow Block Bearing UCP211-33



    Basic Dimensions

    Bore Size

    Center Shaft to Base Size

    Housing Length

    Center Bolt to Bolt Size

    Housing Width

    Housing Bolt Length

    Housing Bolt Width

    Housing Height

    Bolt Size

    2 1/16″

    63.5MM

    219MM

    171MM

    60MM

    25MM

    20MM

    126MM

    5/8



    Technical Data for GJP UCP211-33

    Housing No.: P211

    Bearing Insert No.: UC211-33

    Material For Bearing Insert: 100% Chrome Steel Gcr15(AISI 52100)

    Grade For Steel Ball: G10 Grade Chrome Steel Ball.

    Materia of Bearing Cage: #10 Steel

    Stopping Pin Material on OD of OR: Chrome Steel Gcr15

    Sealing Type: F Seal, L3 Seal And Normal NBR Seal are available for customers’selection.

    Set Screw Material: 35CrMo

    Grease: 20% to 50% Mobil Grease

    Set Screw Surrounding Hardness: HRC49 to HRC 50

    Bearing Race and Steel Ball Hardness: HRC59 to HRC62

    Bearing Housing Material: HT200 Grey Cast Iron

    Housing Color: Green, Blue, Grey, Black Color available.

    Whole Unit Assembly Type: J7 Tight Fitting

    Housing Weight: 2.4KGS

    Quality Control: Under ISO: 9001: 2008 Certificate

    Package: 1*1 Single GJP poly bag+1*1 Single GJP color box+1*1 GJP outer carton



    2 1/16” NTN Four Star Seal Pillow Block Bearing UCP211-33

    2 1/16” NTN Four Star Seal Pillow Block Bearing UCP211-33

    2 1/16” NTN Four Star Seal Pillow Block Bearing UCP211-33

    2 1/16” NTN Four Star Seal Pillow Block Bearing UCP211-33



    GJP advantage:

  • We has two factories of 40000 square meters and totally 78 employees to promise the bearing unit In Stock with best quality control;
  • According to the different shaft diameter and assembly height, GJP could comfortable choose the products which is fit for you.
  • Our motivation is — customers’satisfaction and smile;
  • Our believing is — pay attention to every detail;
  • Our wish is —-perfect co-operation.
  •

    FAQ

    If we become the GJP dealer in our area, does your company hold the annual meeting in all over the world like some Japanese or Europeand brand?

    At present, we don’t held the annual meetings to have all dealer getting together, as it’s our beginning of promoting the GJP Brand in all over the world, we need to need to improve and upgrade, but I’m sure with the time flying and market requests, we would have this kind of meeting in the future, so that we could let all of our GJP dealer getting together, and we could listen what you wanna us to do and improve, even though that we don’t have this kind of meetings, but we normally go and visit our dealer every years to communicate face to face, through this, we know whether there is a problem when promoting our bearings, and how both of us could go ahead.
