1 1/2” Bore Tight Fit J7 Pillow Block Bearing HCP208-24

Description-11/2 Inch Bore Tight Fit Pillow Block Bearing HCP208-24

GJP Bar Code Number: 6935329802728

GJP 1 1/2″ Tight Fit Pillow Block Bearing HCP208-24, which is a eccentric locking collar type, this mounted unit bearing is designed by GJP with high shaft height, long and solid bottom strong base, and for the grease fitting location, GJP could design either on 45 degree, or on the top and at the housing bottom, for bearing, it could be B type or L3-types compound sealing structures which is tight contact between OD of Inner ring and ID of outer ring, for the grease filling, GJP designs this bearings to fill with 25% to 35% Mobile #28 grease for low speed application, and filling with Grade 10 steel ball for AISI 52100 standard material. Beside the eccentric locking collars, if customer need, we also could put some quantity of allen keys in each carton of HCP208-24 for easy operation at end user’s place.

HCP208-24 has the wide application include: Agriculture, Automotive, Construction, Pump, Manufacturing Equipment, Sporting and Consumer Goods, Conveyor and Fan Assemblies, Farm Machinery, HVAC, Feed Mill, Economical housed bearing solution and many other Industrial Equipment.

What is a tight fit pillow block bearing?

A tight fit pillow block bearing is a type of bearing that is specifically designed to fit snugly into a corresponding recess in the mounting surface. This type of bearing is often used in applications where space is limited, and it is important to ensure that the bearing is mounted as securely as possible.

The rolling sound of tight fit pillow block bearing and its control method is the harsh metal friction sound that may occur in cylindrical roller bearings in all occasions. It is more likely to occur in greases with deteriorated performance, and hardly occurs in oil lubrication.

In addition, it is more likely to occur in winter. When it is subjected to pure radial load, it is prone to occur in occasions with large radial clearance, and it is prone to occur in a specific speed range with the difference in the size of the tight fit pillow block flange bearing. It occurs both continuously and intermittently. Adopting a special processing method for the outer ring raceway can prevent the occurrence of rolling noise. If necessary, this kind of bearing can be selected, or the radial clearance of the bearing can be appropriately reduced, the grease with excellent performance is used, and the rigidity of the matching parts of the bearing can be improved. GJP is a China tight fit pillow block bearing supplier, you are welcome to contact us anytime.

What are the benefits of using a tight fit pillow block bearing?

There are many benefits of using a tight fit pillow block bearing. Some of these benefits include:

1. Increased stability – A tight fit pillow block bearing will help to increase the stability of the system by reducing the amount of play in the bearings. This will help to ensure that the system runs smoothly and accurately.
2. Increased accuracy – By reducing the amount of play in the bearings, you will also reduce the amount of inaccuracies in the system. This will help to ensure that the system performs as intended, with minimal errors.
3. Increased life span – A tight fit pillow block bearing will help to keep the bearings in alignment, which will help to extend their life span. This will help to reduce the amount of wear and tear on the bearings, and keep them running for longer.
4. Enhanced performance – By using a tight fit pillow block bearing, you can improve the performance of the system by ensuring that all the parts are working together accurately. This will help to ensure that the system operates at its best possible level.

Interchange

GJP: HCP208-24

AMI: UGP208-24

FYH: NAP208-24

IPTCI: NAP208-24

NSK: HCP208-24

Peer: HCP208-24

NTN: UELP208-108D1

Browning: VPE-224

Dodge: P2B-SXR-108

Fafnir: RAS 1 1/2

Link Belt: P3-Y224N

Seal Master: RP-24E

Turner: HCP208-24

SKF: SY 1 1/2 WF

Technical Data for GJP HCP208-24

Type: Pillow Block Mounted Unit With Eccentric Locking Collar

Housing No.: P208

Bearing Insert No.: HC208-24

Material For Bearing Insert: 100% Chrome Steel Gcr15(AISI 52100)

Grade For Steel Ball: G10 Grade Chrome Steel Ball.

Materia of Bearing Cage: #10 Steel

Stopping Pin Material on OD of OR: Chrome Steel Gcr15

Sealing Type: F Seal, L3 Seal And Normal NBR Seal are available for customers’selection.

Eccentric Locking Collar Material: #45 Carbon Steel

Grease: 20% to 50% Mobil Grease

Set Screw Surrounding Hardness: HRC49 to HRC 50

Bearing Race and Steel Ball Hardness: HRC59 to HRC62

Bearing Housing Material: HT200 Grey Cast Iron

Housing Color: Green, Blue, Grey, Black Color available.

Whole Unit Assembly Type: J7 Tight Fitting

Housing Weight: 2.8KGS

Quality Control: Under ISO: 9001: 2008 Certificate

Package: 1*1 Single GJP poly bag+1*1 Single GJP color box+1*1 GJP outer carton

Basic Loading(Cr): 29.1KN

Basic Loading(Cor): 17.8KN
