1 1/4” Re-lubrication Pillow Block Bearing HCP207-20

1 1/4” Re-lubrication Pillow Block Bearing HCP207-20

The GJP 1 1/4″ Re-lubrication Pillow Block Bearing HCP207-20 is an exceptional choice for heavy-duty applications. This durable bearing boasts an American outer shape style heavy-duty housing that has been designed to withstand heavy loads and provide excellent strength. The housing is crafted with two strong castings near the bolt, and the bolt’s sides can be customized to match the requirements of your equipment.

If you’re looking for a dependable pillow block bearing that can handle the toughest industrial environments, the GJP HCP207-20 is an excellent choice. Its high-quality manufacturing ensures long-lasting performance while its robust housing design provides superior strength and toughness.

One of the standout features of this pillow block bearing is its re-lubrication capability. By allowing for easy lubrication of the bearing, you can extend its service life and reduce the risk of premature failure. This makes it an ideal option for applications where sustainability is a priority.

In addition to its technical features, the GJP HCP207-20 pillow block bearing is also easy to install and maintain. So, if you’re looking for a versatile, reliable, and cost-effective bearing solution for your machinery, you can’t go wrong with the GJP HCP207-20 pillow block bearing.

Product Details

Description-11/4 Inch Bore Re-lubrication Pillow Block Bearing HCP207-20

GJP Bar Code Number: 6935329802674

GJP 1 1/4″ Re-lubrication Pillow Block Bearing HCP207-20 with American outer shape stype heavy duty housing, which has a feature for affording heavy duty load, and better strength capacity, the housing are produced with two higher casting near the bolt, and bolt sides could be produced according to customers’ machinery requests, for the insert ball bearings, GJP designed the bearing race and steel ball with case hardened entirely, and sealed with triple seal to gurantee and protect the dust entering into the bearing inside, the whole bearing unit was designed by GJP to ensure good rotation for the insert bearings together when the outer housing was locked on the machinery.

HCP207-20 are commonly used on agriculture, automotive, pumps, fan assemblies, economical housed bearing solution and many other industrial equipment.



Why Do Bearings Need Lubrication?

  1. Reduce friction and wear. Obviously, after lubrication, the friction of the bearing will inevitably be reduced, the friction will be reduced, and the wear will naturally decrease.
  2. Take away frictional heat. Compared with metal, lubricant has higher specific heat capacity and slower temperature rise, so it can effectively reduce the bearing temperature rise. At the same time, the flow of lubricant can conduct temperature and take away the bearing friction temperature as much as possible.
  3. Extend the life of the bearing. The wear is reduced, the temperature rise is also reduced, and the lifespan is naturally extended.
  4. Prevent rust. The root cause of rust is oxidation reaction. Through the isolation of oil film, the bearing metal surface is kept away from oxygen, away from oxidation reaction, and away from rust.
  5. Prevent foreign body intrusion. Through the filling of lubricant (especially solid grease), foreign matter will not invade the bearing rolling element, such as a piece of sand, which is usually nothing, but in the high-speed rotating rolling element environment, a negligible sand, for the bearing, often fatal.

Re-lubricating pillow block bearings can provide a number of benefits, including:

– Reduced wear and tear on the bearings.

– Improved performance and lifespan of the bearings.

– Reduced friction and heat build-up.

– Reduced noise and vibration.



Interchange

GJP: HCP207-20

AMI: UGP207-20

FYH: NAP207-20

IPTCI: NAP207-20

NSK: HCP207-20

Peer: HCP207-20

NTN: UELP207-104D1

Browning: VPE-220

Dodge: P2B-SXR-104

Fafnir: RAS 1 1/4

Link Belt: P3-Y220N

Seal Master: RP-20E

Turner: HCP207-20

SKF: SY 1 1/4 WF



1 1/4” Re-lubrication Pillow Block Bearing HCP207-20

Basic Dimensions

Bore Size

Center Shaft to Base Size

Housing Length

Center Bolt to Bolt Size

Housing Width

Housing Bolt Length

Housing Bolt Width

Housing Height

Bolt Size

1 1/4″

47.6MM

167MM

127MM

48MM

21MM

17MM

94MM

1/2″

Technical Data for GJP HCP207-20

Type: Pillow Block Mounted Unit With Eccentric Locking Collar

Housing No.: P207

Bearing Insert No.: HC207-20

Material For Bearing Insert: 100% Chrome Steel Gcr15(AISI 52100)

Grade For Steel Ball: G10 Grade Chrome Steel Ball.

Materia of Bearing Cage: #10 Steel

Stopping Pin Material on OD of OR: Chrome Steel Gcr15

Sealing Type: F Seal, L3 Seal And Normal NBR Seal are available for customers’selection.

Eccentric Locking Collar Material: #45 Carbon Steel

Grease: 20% to 50% Mobil Grease

Set Screw Surrounding Hardness: HRC49 to HRC 50

Bearing Race and Steel Ball Hardness: HRC59 to HRC62

Bearing Housing Material: HT200 Grey Cast Iron

Housing Color: Green, Blue, Grey, Black Color available.

Whole Unit Assembly Type: J7 Tight Fitting

Housing Weight: 2.25KGS

Quality Control: Under ISO: 9001: 2008 Certificate

Package: 1*1 Single GJP poly bag+1*1 Single GJP color box+1*1 GJP outer carton

Basic Loading(Cr): 25.7KN

Basic Loading(Cor): 15.4KN



Pillow Block Bearing HCP207-20

HCP207-20

Pillow Block Bearing

Pillow Block Bearing
